| Nama Wahi | C042FAN01.8 |
| Waitohu | AUO |
| Rahi | 4.2 |
| Taupānga | Outdoor High Brightn |
| Whakatau | 480×272 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 262K |
| Whakamuri | 3S2P |
| Atanga | |
| manufacturer | AUO |
| model name | C042FAN01.8 |
| screen size | 4.2 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 480(RGB)×272 (WQVGA) 131PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 92.88 × 52.632 (H×V) |
| outline(mm) | 102.8 × 68.52 × 20 (H×V×D) |
| bezel area(mm) | - |
| treatment | Antiglare |
| luminance | 700 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 80/80/80/80 (Min.)(CR≥10) |
| response | 13/14 (Typ.)(Tr/Td) ms |
| good view at | Symmetry |
| work mode | AHVA, Normally Black, Transmissive |
| color depth | 262K 71% NTSC |
| backlight | 3S2P WLED , 10K hours , No Driver |
| mass | 89.8g (Typ.) |
| used for | Outdoor High Brightness Automotive Display |
| refresh rate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
