| Nama Wahi | B170PW02 V0 |
| Waitohu | AUO |
| Rahi | 17.0 |
| Taupānga | NBPC |
| Whakatau | 1440×900 |
| Te tito | LCM |
| Tirohanga | 385 |
| CR | 400:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | AUO |
| panel model | B170PW02 V0 3 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 17.0 inch |
| resolution | 1440(RGB)×900 , WXGA+ |
| display mode | TN, Normally White, Transmissive |
| active area | 367.2×229.5 mm |
| outline | 382.2×246.8×10 mm |
| shape style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| surface | Glare (Haze 0%), Antireflection |
| brightness | 385 cd/m² (Typ.) |
| contrast ratio | 400:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 12/4 (Typ.)(Tr/Td) |
| viewing angle | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 6-bit), 30 pins |
| input voltage | 3.3V (Typ.) |
| application | NBPC |
| B170PW01 V1 | AUO | 17.0 | 1440×900 |
| B170PW02 V0 | AUO | 17.0 | 1440×900 |
| B170PW03 V0 | AUO | 17.0 | 1440×900 |
| B170PW03 V1 | AUO | 17.0 | 1440×900 |
| B170PW03 V3 | AUO | 17.0 | 1440×900 |
| B170PW03 V4 | AUO | 17.0 | 1440×900 |
| B170PW03 V5 | AUO | 17.0 | 1440×900 |
| B170PW06 V2 | AUO | 17.0 | 1440×900 |
| B170PW06 V3 | AUO | 17.0 | 1440×900 |
| B170PW07 V0 | AUO | 17.0 | 1440×900 |
| B141XN03 V0 | AUO | 14.1 | 1024×768 |
| B156HAT01.0 | AUO | 15.6 | 1920×1080 |
| CLAA154WB09A | CPT | 15.4 | 1280×800 |
| LTD131EQ2X | TOSHIBA | 13.1 | 1600×900 |
| LTD133EV2F | TOSHIBA | 13.3 | 1280×800 |
| LTN140AT01-G01 | Samsung | 14.0 | 1366×768 |
| LTN154U2-L03 | Samsung | 15.4 | 1920×1200 |
| M125NWR3 R0 | IVO | 12.5 | 1366×768 |
| M133NWF2 R0 | IVO | 13.3 | 1920×1080 |
| N133I6-L09 | Innolux | 13.3 | 1280×800 |
