| Nama Wahi | B156XTT01.2 |
| Waitohu | AUO |
| Rahi | 15.6 |
| Taupānga | Laptop |
| Whakatau | 1366×768 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| manufacturer | AUO |
| screen size | 15.6 inch |
| pixel number | 1366(RGB)×768 (WXGA) 100PPI |
| active area(mm) | 344.232 × 193.536 (H×V) |
| bezel area(mm) | - |
| luminance | 200 cd/m² (Typ.) |
| viewing angle | 45/45/15/35 (Typ.)(CR≥10) |
| good view at | 6 o'clock |
| color depth | 262K 45% NTSC |
| outline shape | Slim (PCBA Flat, T≤3.2mm) |
| refresh rate | 60Hz |
| signal type | LVDS (1 ch, 6-bit) , 40 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| model name | B156XTT01.2 (AUO12EC) |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 364.9 × 224.56 × 5.2 (H×V×D) |
| treatment | Glare (Haze 0%), Hard coating (7H) |
| contrast ratio | 500 : 1 (Typ.) (TM) |
| response | 8 (Typ.)(G to G) ms |
| work mode | TN, Normally White, Transmissive |
| backlight | WLED , 15K hours , With LED Driver |
| used for | Laptop |
| touchscreen | PCAP, Optical Bonding |
