| Nama Wahi | B156XTN07.0 HWKA |
| Waitohu | AUO |
| Rahi | 15.6 |
| Taupānga | Laptop |
| Whakatau | 1366×768 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | eDP |
| panel brand | AUO |
| panel model | B156XTN07.0 HWKA |
| panel size | 15.6" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1366(RGB)×768, WXGA, 100PPI |
| pixel format | RGB Vertical Stripe |
| display area | 344.232(W)×193.536(H) mm |
| bezel opening | - |
| outline size | 359.5(W)×223.8(H) mm |
| surface | - |
| brightness | - |
| contrast ratio | 500:1 (Typ.) (TM) |
| viewing angle | 45/45/15/35 (Typ.)(CR≥10) |
| display mode | TN, Normally White, Transmissive |
| best view on | 6 o'clock |
| response time | 8 (Typ.)(Tr+Td) |
| display colors | 262K |
| lamp type | WLED |
| frequency | - |
| touch screen | Without |
| shape style | Slim (PCBA Flat, T≤3.2mm) |
| application | Laptop |
| signal interface | eDP (1 Lane) , 30 pins Connector |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
