| Nama Wahi | B156XTK02.0 |
| Waitohu | AUO |
| Rahi | 15.6 |
| Taupānga | Laptop |
| Whakatau | 1366×768 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | eDP |
| manufacturer | AUO |
| model name | B156XTK02.0 (AUO20EC) |
| screen size | 15.6 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 1366(RGB)×768 (WXGA) 100PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 344.23 × 193.54 (H×V) |
| outline(mm) | 350.66 × 216.15 × 3.2 (H×V×D) |
| bezel area(mm) | - |
| treatment | Glare (Haze 0%) |
| luminance | 220 cd/m² (Typ.) |
| contrast ratio | 500 : 1 (Typ.) (TM) |
| viewing angle | 45/45/15/35 (Typ.)(CR≥10) |
| response | 8 (Typ.)(Tr+Td) ms |
| good view at | 6 o'clock |
| work mode | TN, Normally White, Transmissive |
| color depth | 262K 44% NTSC |
| backlight | WLED , 15K hours , With LED Driver |
| outline shape | Slim (PCBA Flat, T≤3.2mm) |
| used for | Laptop |
| refresh rate | 60Hz |
| touchscreen | On-Cell Touch |
| signal type | eDP (1 Lane) , eDP1.2 , 40 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
