Nama Wahi | B141PW04 V0 HW0A |
Waitohu | AUO |
Rahi | 14.1 |
Taupānga | NBPC |
Whakatau | 1440×900 |
Te tito | LCM |
Tirohanga | 300 |
CR | 400:1 |
Nga Tae | 262K |
Whakamuri | WLED |
Atanga | LVDS |
panel brand | AUO |
panel model | B141PW04 V0 HW0A 3 Compatible model |
panel type | a-Si TFT-LCD , LCM |
panel size | 14.1 inch |
resolution | 1440(RGB)×900 , WXGA+ |
display mode | TN, Normally White, Transmissive |
active area | 303.48×189.675 mm |
outline | 319.5×205.5×5.5 mm |
shape style | Wedge (PCBA Bent, Depth ≥5.2mm) |
surface | Antiglare (Haze 11%), Hard coating (3H) |
brightness | 300 cd/m² (Typ.) |
contrast ratio | 400:1 (Min.) |
display colors | 262K (6-bit) |
response time | 8 (Typ.)(Tr+Td) |
viewing angle | 40/40/10/30 (Typ.)(CR≥10)(L/R/U/D) |
frequency | 60Hz |
lamp type | WLEDEmbedded (LED Driver) |
signal interface | LVDS (2 ch, 6-bit), 50 pins |
input voltage | 3.3V (Typ.) |
application | NBPC |
