| Nama Wahi | B140QAN01.3 |
| Waitohu | AUO |
| Rahi | 14.0 |
| Taupānga | Laptop |
| Whakatau | 2560×1440 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 700:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | eDP |
| manufacturer | AUO |
| screen size | 14.0 inch |
| pixel number | 2560(RGB)×1440 (Quad-HD) 210PPI |
| active area(mm) | 309.35 × 174.01 (H×V) |
| luminance | - |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| good view at | Symmetry |
| color depth | 16.7M |
| outline shape | Slim (PCBA Flat, T≤3.2mm) |
| refresh rate | 60Hz |
| signal type | eDP (4 Lanes) Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| model name | B140QAN01.3 |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 320.4 × 198.6 × 2.6 (H×V×D) |
| contrast ratio | 700 : 1 (Typ.) (TM) |
| response | 25 (Typ.)(Tr+Td) ms |
| work mode | AHVA, Normally Black, Transmissive |
| backlight | WLED , 15K hours , With LED Driver |
| used for | Laptop |
| touchscreen | Without |
