Nama Wahi | B133HAN04.3 |
Waitohu | AUO |
Rahi | 13.3 |
Taupānga | Laptop |
Whakatau | 1920×1080 |
Te tito | LCM, a-Si TFT-LCD |
Tirohanga | |
CR | 800:1 |
Nga Tae | 262K |
Whakamuri | WLED |
Atanga | eDP |
manufacturer | AUO |
model name | B133HAN04.3 |
screen size | 13.3 inch |
screen type | LCM, a-Si TFT-LCD |
pixel number | 1920(RGB)×1080 (FHD) 166PPI |
arrangement | RGB Vertical Stripe |
active area(mm) | 293.472 × 165.078 (H×V) |
outline(mm) | 306.3 × 195.29 × 3.2 (H×V×D) |
luminance | - |
contrast ratio | 800 : 1 (Typ.) (TM) |
viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
response | 27 (Typ.)(Tr+Tf) ms |
good view at | Symmetry |
work mode | AHVA, Normally Black, Transmissive |
color depth | 262K |
backlight | WLED , 15K hours , With LED Driver |
outline shape | Slim (PCBA Flat, T≤3.2mm) |
used for | Laptop |
refresh rate | 60Hz |
touchscreen | Without |
signal type | eDP (2 Lanes) , eDP1.2 , Connector 30 pins |
voltage supply | 3.3V (Typ.) |
max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
