| Nama Wahi | B125HAN03.1 |
| Waitohu | AUO |
| Rahi | 12.5 |
| Taupānga | Laptop |
| Whakatau | 1920×1080 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.2M |
| Whakamuri | WLED |
| Atanga | eDP |
| brand | AUO |
| diagonal size | 12.5 inch |
| pixel format | 1920(RGB)×1080 [FHD] 176PPI |
| active area | 276.48(H)×155.52(V) mm |
| bezel area | - |
| luminance | 400 cd/m² (Typ.) |
| view direction | Symmetry |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| support color | 16.2M 99% sRGB |
| form style | Slim (PCBA Flat, T≤3.2mm) |
| frame rate | 60Hz |
| interface type | eDP (2 Lanes) , eDP1.3 , 30 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | B125HAN03.1 (AUO316D) |
| type | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| outline dim. | 282.4(H)×179.32(V) ×2.5(D) mm |
| treatment | Glare (Haze 0%) |
| contrast ratio | 800:1 (Typ.) (TM) |
| response time | 27 (Typ.)(Tr+Td) |
| operating mode | AHVA, Normally Black, Transmissive |
| light source | WLED , 15K hours , With LED Driver |
| designed for | Laptop |
| touch panel | Without |
