| Nama Wahi | AMS258DN01 |
| Waitohu | SAMSUNG |
| Rahi | 2.6 |
| Taupānga | Mobile Phone |
| Whakatau | 240×320 |
| Te tito | OLED, AM-OLED |
| Tirohanga | |
| CR | |
| Nga Tae | 16.7M |
| Whakamuri | self |
| Atanga | 8-bit |
| manufacturer | SAMSUNG |
| model name | AMS258DN01 |
| screen size | 2.6 inch |
| screen type | OLED, AM-OLED |
| pixel number | 240(RGB)×320 (QVGA) 154PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 39.6 × 52.48 (H×V) |
| outline(mm) | 44.48 × 62.35 (H×V×D) |
| viewing angle | - |
| response | - |
| good view at | Symmetry |
| work mode | - |
| color depth | 16.7M |
| backlight | self |
| mass | TBD |
| used for | Mobile Phone |
| refresh rate | - |
| touchscreen | Without |
| signal type | 8-bit 8080 parallel , Connector 24 pins |
| voltage supply | 1.65/2.8/4.6/-5.0V (Typ.)(VDDIO/VPNL/ELVDD/ELVSS) |
| max. ratings | Storage Temp.: -40 ~ 80 °C Operating Temp.: -30 ~ 70 °C |
| A026EAN01.0 | AUO | 2.6 | 800×1280 |
| AMDM001 | Samsung | 2.6 | 240×400 |
| AMS260CM61 | Samsung | 2.6 | 240×320 |
| L5F30774P01 | Epson | 2.6 | 240×320 |
| LS026B8PX04 | SHARP | 2.6 | 240×400 |
| LS026Q3DX01 | SHARP | 2.6 | 240×320 |
| LS026Q7UX01 | SHARP | 2.6 | 320×240 |
| TD026TTEA1 | TPO | 2.6 | 480×640 |
