| Nama Wahi | AM480272H3TMQW-TW1H |
| Waitohu | AMPIRE |
| Rahi | 4.3 |
| Taupānga | Industrial |
| Whakatau | 480×272 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 250:1 |
| Nga Tae | 65K/262K |
| Whakamuri | WLED |
| Atanga | 8/9/16/18-bit |
| brand | AMPIRE |
| model | AM480272H3TMQW-TW1H |
| diagonal size | 4.3 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 480(RGB)×272 [WQVGA] 128PPI |
| configuration | RGB Vertical Stripe |
| active area | 95.04(H)×53.856(V) mm |
| outline dim. | 105.5(H)×67.2(V) ×7.91(D) mm |
| luminance | 400 cd/m² (Typ.) |
| contrast ratio | 250:1 (Typ.) (TM) |
| view direction | 6 o'clock |
| response time | 15/35 (Typ.)(Tr/Td) |
| viewing angle | 70/70/35/55 (Typ.)(CR≥10) |
| operating mode | TN, Normally White, Transmissive |
| support color | 65K/262K 52% NTSC |
| light source | WLED [7S1P] , 15K hours , W/O Driver |
| weight | TBD |
| designed for | Industrial |
| frame rate | 60Hz |
| touch panel | 4-wire Resistive Touch |
| interface type | 8/9/16/18-bit 6800/8080 parallel , 40 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
