| Nama Wahi | AM-800480LATMQW-TN0H-L |
| Waitohu | AMPIRE |
| Rahi | 5.0 |
| Taupānga | Industrial |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 250:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | Parallel |
| brand | AMPIRE |
| diagonal size | 5.0 inch |
| pixel format | 800(RGB)×480 [WVGA] 188PPI |
| active area | 108(H)×64.8(V) mm |
| luminance | 360 cd/m² (Typ.) |
| view direction | - |
| viewing angle | 70/70/70/50 (Typ.)(CR≥10) |
| support color | 16.7M 52% NTSC |
| weight | - |
| frame rate | 60Hz |
| interface type | Parallel RGB (1 ch, 8-bit) , 45 pins FPC |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | AM-800480LATMQW-TN0H-L |
| type | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| outline dim. | 118.5(H)×74(V) ×5.16(D) mm |
| contrast ratio | 250:1 (Typ.) (TM) |
| response time | 15/35 (Max.)(Tr/Td) |
| operating mode | TN, Normally White, Transflective |
| light source | WLED [3S6P] , W/O Driver |
| designed for | Industrial |
| touch panel | PCAP |
