| Nama Wahi | AM-640480V2TZQW-TA7H |
| Waitohu | AMPIRE |
| Rahi | 5.7 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 640×480 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1200:1 |
| Nga Tae | 262K |
| Whakamuri | 4S7P |
| Atanga | LVDS |
| panel brand | AMPIRE |
| panel model | AM-640480V2TZQW-TA7H |
| panel size | 5.7" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 640(RGB)×480, VGA, 141PPI |
| pixel format | RGB Vertical Stripe |
| display area | 115.2(W)×86.4(H) mm |
| bezel opening | - |
| outline size | 127(W)×98.43(H) ×10.88(D) mm |
| surface | - |
| brightness | 850 cd/m² (Typ.) |
| contrast ratio | 1200:1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| display mode | IPS, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 30 (Typ.)(Tr+Td) |
| display colors | 262K 60% NTSC |
| lamp type | 4S7P WLED , 50K hours , With LED Driver |
| frequency | 60Hz |
| touch screen | PCAP |
| panel weight | - |
| application | Industrial Outdoor High Brightness |
| signal interface | LVDS (1 ch, 6-bit) , 20 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| CLAA057VA02CW | CPT | 5.7 | 640×480 |
| EL320.240.36 AG | Lumineq | 5.7 | 320×240 |
| G057QTN01.1 | AUO | 5.7 | 320×240 |
| KCG057QV1DB-G56 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G00 | Kyocera | 5.7 | 320×240 |
| LQ057Q3DG02 | SHARP | 5.7 | 320×240 |
| LTA057A347F | TOSHIBA | 5.7 | 320×240 |
| MST-G320240DBSW-213W-E | Other | 5.7 | 320×240 |
| PD057VU4 | E Ink | 5.7 | 320×240 |
| TM057QDHG04 | Tianma | 5.7 | 640×480 |
