| Nama Wahi | AM-640480G2TNQW-T08H |
| Waitohu | AMPIRE |
| Rahi | 5.7 |
| Taupānga | Industrial |
| Whakatau | 640×480 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 250:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | Parallel |
| manufacturer | AMPIRE |
| model name | AM-640480G2TNQW-T08H |
| screen size | 5.7 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 640(RGB)×480 (VGA) 141PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 115.2 × 86.4 (H×V) |
| outline(mm) | 127 × 98.43 × 10.2 (H×V×D) |
| bezel area(mm) | 118.0 × 89.2 (H×V) |
| treatment | - |
| luminance | 200 cd/m² (Typ.) |
| contrast ratio | 250 : 1 (Typ.) (TM) |
| viewing angle | 70/70/50/50 (Typ.)(CR≥10) |
| response | 50 (Typ.)(Tr+Td) ms |
| good view at | 12 o'clock |
| work mode | TN, Normally White, Transmissive |
| color depth | 262K 50% NTSC |
| backlight | WLED , 20K hours , With LED Driver |
| mass | - |
| used for | Industrial |
| refresh rate | 60Hz |
| touchscreen | 4-wire Resistive Touch |
| signal type | Parallel RGB (1 ch, 6-bit) , Connector 40 pins |
| voltage supply | 3.3/5.0V (Typ.)(VCC/VDD) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
