| Nama Wahi | AM-480272METMQW-00H |
| Waitohu | AMPIRE |
| Rahi | 4.3 |
| Taupānga | Industrial |
| Whakatau | 480×272 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 16.7M |
| Whakamuri | 6S2P |
| Atanga | Parallel |
| manufacturer | AMPIRE |
| model name | AM-480272METMQW-00H |
| screen size | 4.3 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 480(RGB)×272 (WQVGA) 128PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 95.04 × 53.856 (H×V) |
| outline(mm) | 105.5 × 67.2 (H×V×D) |
| bezel area(mm) | 99.0 × 56.86 (H×V) |
| treatment | Antiglare, Hard coating (3H) |
| luminance | 500 cd/m² (Typ.) |
| contrast ratio | 500 : 1 (Typ.) (TM) |
| viewing angle | 70/70/50/70 (Typ.)(CR≥10) |
| response | 8/17 (Typ.)(Tr/Td) ms |
| good view at | 12 o'clock |
| work mode | TN, Normally White, Transmissive |
| color depth | 16.7M |
| backlight | 6S2P WLED , 25K hours , No Driver |
| mass | - |
| used for | Industrial |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | Parallel RGB (1 ch, 8-bit) , FPC 40 pins |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
