| Nama Wahi | AM-320240N1TMQW-TW0H-A(R) |
| Waitohu | AMPIRE |
| Rahi | 5.7 |
| Taupānga | Industrial |
| Whakatau | 320×240 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 350:1 |
| Nga Tae | 65K/262K |
| Whakamuri | 3S7P |
| Atanga | |
| manufacturer | AMPIRE |
| model name | AM-320240N1TMQW-TW0H-A(R) |
| screen size | 5.7 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 320(RGB)×240 (QVGA) 70PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 115.2 × 86.4 (H×V) |
| outline(mm) | 167 × 109 × 14.8 (H×V×D) |
| bezel area(mm) | 118.2 × 89.4 (H×V) |
| treatment | - |
| luminance | 400 cd/m² (Typ.) |
| contrast ratio | 350 : 1 (Min.) (TM) |
| viewing angle | 70/70/50/70 (Typ.)(CR≥10) |
| response | 15/35 (Typ.)(Tr/Td) ms |
| good view at | 6 o'clock |
| work mode | TN, Normally White, Transmissive |
| color depth | 65K/262K 61% NTSC |
| backlight | 3S7P WLED , No Driver |
| mass | TBD |
| used for | Industrial |
| refresh rate | 60Hz |
| touchscreen | 4-wire Resistive Touch |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AM-320240N1TMQW-T30H-D(R) | AMPIRE | 5.7 | 320×240 |
| CLAA057VC01CW | CPT | 5.7 | 640×480 |
| EL320.240.36 HB | Lumineq | 5.7 | 320×240 |
| G057QTN01.1 | AUO | 5.7 | 320×240 |
| H572DAN01.2 | AUO | 5.7 | 1080×1920 |
| LQ057V3LG11 | SHARP | 5.7 | 640×480 |
| MST-G320240DBSW-213W-E | Other | 5.7 | 320×240 |
| NL6448BC18-06F | NLT | 5.7 | 640×480 |
| SP14Q001 | KOE | 5.7 | 320×240 |
| TCG057QVLAC-G00 | Kyocera | 5.7 | 320×240 |
