| Nama Wahi | AM-1280800W2TZQW-00H |
| Waitohu | AMPIRE |
| Rahi | 10.1 |
| Taupānga | Industrial |
| Whakatau | 1280×800 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | 7S4P |
| Atanga | LVDS |
| manufacturer | AMPIRE |
| screen size | 10.1 inch |
| pixel number | 1280(RGB)×800 (WXGA) 149PPI |
| active area(mm) | 216.96 × 135.6 (H×V) |
| bezel area(mm) | - |
| luminance | 1000 cd/m² (Typ.) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| good view at | Symmetry |
| color depth | 16.7M 44% NTSC |
| mass | 160g (Max.) |
| refresh rate | 60Hz |
| signal type | LVDS (1 ch, 8-bit) , 40 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| model name | AM-1280800W2TZQW-00H |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 231 × 154.4 × 7.9 (H×V×D) |
| treatment | Glare (Haze 0%), Hard coating (3H) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| response | 25 (Typ.)(Tr+Td) ms |
| work mode | ADS, Normally Black, Transmissive |
| backlight | 7S4P WLED , 50K hours , No Driver |
| used for | Industrial |
| touchscreen | Without |
