| Nama Wahi | AM-1024600K7TMQW-T53H |
| Waitohu | AMPIRE |
| Rahi | 7.0 |
| Taupānga | Industrial |
| Whakatau | 1024×600 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 700:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | 5S3P |
| Atanga | LVDS |
| panel brand | AMPIRE |
| panel size | 7.0" |
| resolution | 1024(RGB)×600, WSVGA, 169PPI |
| display area | 153.6(W)×90(H) mm |
| outline size | 165.5(W)×104.44(H) ×11.93(D) mm |
| brightness | 425 cd/m² (Typ.) |
| viewing angle | 75/75/70/75 (Typ.)(CR≥10) |
| best view on | 6 o'clock |
| display colors | 262K/16.7M |
| frequency | 60Hz |
| panel weight | TBD |
| signal interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| panel model | AM-1024600K7TMQW-T53H |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| surface | - |
| contrast ratio | 700:1 (Typ.) (TM) |
| display mode | TN, Normally White, Transmissive |
| response time | 20/20 (Typ.)(Tr/Td) |
| lamp type | 5S3P WLED , 50K hours , With LED Driver |
| touch screen | PCAP |
| application | Industrial |
