| Nama Wahi | AA078AA01 |
| Waitohu | Mitsubishi |
| Rahi | 7.8 |
| Taupānga | IA |
| Whakatau | 800×300 |
| Te tito | LCM |
| Tirohanga | 500 |
| CR | 1000:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | Mitsubishi |
| panel model | AA078AA01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.8 inch(8/15 cut of 8.5") |
| resolution | 800(RGB)×300 |
| display mode | IPS, Normally Black, Transmissive |
| active area | 184.8×69.3 mm |
| outline | 207×86 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 500 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) |
| display colors | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| response time | 12/12 (Typ.)(Tr/Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6/8-bit) |
| input voltage | 12.0V (Typ.) |
| application | IA |
