| Nama Wahi | A050FTT04.0 |
| Waitohu | AUO |
| Rahi | 5.0 |
| Taupānga | Portable Navigation |
| Whakatau | 480×272 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | Parallel |
| brand | AUO |
| diagonal size | 5.0 inch |
| pixel format | 480(RGB)×272 [WQVGA] 109PPI |
| active area | 110.88(H)×62.832(V) mm |
| bezel area | - |
| luminance | 400 cd/m² (Typ.) |
| view direction | 6 o'clock |
| viewing angle | 70/70/40/60 (Typ.)(CR≥10) |
| support color | 262K 50% NTSC |
| weight | 75g |
| frame rate | - |
| interface type | Parallel RGB (1 ch, 6-bit) + SPI , 67 pins FPC |
| power supply | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | A050FTT04.0 |
| type | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| outline dim. | 120.73(H)×75.83(V) ×4.47(D) mm |
| treatment | Hard coating (3H) |
| contrast ratio | 500:1 (Typ.) (TM) |
| response time | 7/23 (Typ.)(Tr/Td) |
| operating mode | TN, Normally White, Transmissive |
| light source | WLED [6S2P] , 10K hours , W/O Driver |
| designed for | Portable Navigation MP3 PMP |
| touch panel | 4-wire Resistive Touch |
