| Nama Wahi | 990001260 |
| Waitohu | Chimei Innolux |
| Rahi | 2.7 |
| Taupānga | Digital Still Camera |
| Whakatau | 960×480 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | |
| brand | Chimei Innolux |
| model | 990001260 |
| diagonal size | 2.7 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 960×480 [HVGA] 217PPI |
| configuration | RGB Delta |
| active area | 54(H)×40.512(V) mm |
| outline dim. | 63.7(H)×46.6(V) ×2.2(D) mm |
| bezel area | - |
| treatment | Hard coating |
| luminance | 500 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) (TM) |
| view direction | - |
| response time | 35 (Typ.)(Tr+Td) |
| viewing angle | 60/60/50/55 (Typ.)(CR≥10) |
| operating mode | TN, Normally White, Transmissive |
| support color | 16.7M |
| light source | WLED [5S1P] , W/O Driver |
| weight | TBD |
| designed for | Digital Still Camera Digital Video Camera |
| frame rate | - |
| touch panel | Without |
| Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -30 ~ 80 °C |
